Supermicro SuperServer SSG-6019P-ACR12L

Call for price

In stock

SKU

SSG-6019P-ACR12L

Key Features:
• Dual socket P (LGA 3647) supports
• Intel® Xeon® Scalable Processors
• Up to 1.5TB of memory
• 12 Hot-swap 3.5" SAS3/SATA3
• 4 Hot-swap 2.5" 7mm NVMe/SATA drive bays
• 600W Redundant Power Supplies Platinum Level Certified

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Supermicro SuperServer SSG-6019P-ACR12L

Product SKU
SSG-6019P-ACR12L	• SuperServer 6019P-ACR12L (Black)

Motherboard
	• Super X11DDW-NT

Processor/Cache
CPU	• Dual Socket P (LGA 3647) • Intel® Xeon® Scalable Processors, Dual UPI up to 10.4GT/s • Support CPU TDP up to 165W
Cores	• Up to 28 Cores with Intel® HT Technology

System Memory
Memory Capacity	• 12 DIMM slots • Up to 1.5TB ECC 3DS LRDIMM, 768GB ECC RDIMM, DDR4 up to 2666MHz
Memory Type	• 2666/2400/2133MHz ECC DDR4 SDRAM

On-Board Devices
Chipset	• Intel® C622 chipset
SATA	• SATA3 (6Gbps); RAID 0, 1, 5, 10
SAS	• Broadcom 3224 SAS3 IT mode controller
Network Controllers	• Dual LAN with 10GBase-T from Intel C622
IPMI	• Support for Intelligent Platform Management Interface v.2.0 • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Video	• ASPEED AST2500 BMC

Input/Output
LAN	• 2 RJ45 10GBase-T LAN ports • 1 RJ45 Dedicated IPMI LAN port
USB	• 4 USB 3.0 ports (rear) • 2 USB 2.0 ports (front)
Video	• 1 VGA port
TPM	• 1 TPM Header

System BIOS
BIOS Type	• UEFI 256Mb

Management
Software	• Intel® Node Manager • IPMI 2.0 • KVM with dedicated LAN • SSM, SPM, SUM • SuperDoctor® 5 • Watch Dog
Power Configuration	• ACPI / APM Power Management

PC Health Monitoring
CPU	• Monitors for CPU Cores, Chipset Voltages, Memory • 4+1 Phase-switching voltage regulator
FAN	• Fans with tachometer monitoring • Status monitor for speed control • Pulse Width Modulated (PWM) fan connectors
Temperature	• Monitoring for CPU and chassis environment • Thermal Control for fan connectors

Chassis
Form Factor	• 1U Rackmount
Model	• CSE-802TS-R606WBP

Dimension and Weight
Width	• 17.6" (447mm)
Height	• 1.7" (43mm)
Depth	• 37.40" (950mm)**
Gross Weight	• 80 lbs (36.3 kg)
Available Colors	• Black

Front Panel
Buttons	• Power On/Off button • System Reset button
LEDs	• Power status LED • HDD activity LED • Network activity LEDs

Expansion Slots
PCI-Express	• 1 PCI-E 3.0 x32 Left Riser slot (HHHL) • 1 PCI-E 3.0 x16 Right Riser slot (LP) • 1 PCI-E 3.0 x16 for Add-On-Module (AOM)

Drive Bays
Hot-swap	• 12 Hot-swap 3.5" SAS3/SATA3 drive bays • 4 Hot-swap 2.5" 7mm NVMe/SATA drive bays

System Cooling
Fans	• 6x 40x40x56mm 20.5K-17.6K RPM Counter-rotating fans

Power Supply with Power Distributor
	• 600W Redundant Power Supplies with PMBus
Total Output Power	• 600W
Dimension (W x H x L)	• 54.5 x 40 x 220 mm
Input	• 100-240V, 50-60Hz, 7.5-3.5A
+12V	• Max: 50A / Min: 0.5A
+5Vsb	• Max: 3A / Min: 0A
Output Type	• Gold Finger Connector Mating with Molex 45984-4343
Certification	• Platinum Certified

Operating Environment
RoHS	• RoHS Compliant
Environmental Spec.	• Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) • Operating Relative Humidity: 8% to 90% (non-condensing) • Non-operating Relative Humidity: 5% to 95% (non-condensing)
