ST1000NX0303

SPECIFICATIONS

• Capacity: 1TB
• Seagate Secure™ Model: ST1000NX0343
• Seagate Secure SED-FIPS Model: —
• Interface: SATA 6Gb/s

FEATURES AND PERFORMANCE

• PowerChoice™ Technology: Yes
• Protection Information: No
• Low Halogen: Yes
• Seagate RAID Rebuild®: Yes
• Spindle Speed (RPM): 7200RPM
• Cache, Multisegmented (MB): 128
• Interface Access Speed (Gb/s): 6.0, 3.0, 1.5
• Max. Sustained Transfer Rate OD (MB/s): 136MB/s
• Average Latency (ms): 4.16
• Interface Ports: Single
• Rotation Vibration @ 1800Hz (rad/s²): 16
• PowerChoice(TM) Technology (Standby) (W): 1.14

RELIABILITY

• MTBF: 2,000,000hr
• Reliability Rating @ Full 24×7 Operation (AFR): 0.44%
• Nonrecoverable Read Errors per Bits Read, Max: 1 sector per 10E15
• Power-On Hours per Year (24×7): 8760
• Sector Size (Bytes per Logical Sector): 4K
• Limited Warranty (years): 5
• Vibration, Operating, 5Hz to 500Hz (Grms): 0.5
• Vibration, Nonoperating, 5Hz to 500Hz (Grms): 3

POWER MANAGEMENT

• Average Idle Power (W): 3.51
• Typical Operating, Random Read (W): 4.74
• Power Supply Requirements: +12V and +5V

PHYSICAL

• Height (in/mm): 0.591in/15.00mm
• Width (in/mm): 2.760in/70.10mm
• Depth (in/mm): 3.955in/100.45mm
• Weight (g/lb): 190g/0.419lb
• Carton Unit Quantity: 40
• Cartons per Pallet/Cartons per Layer: 60/10

ENVIRONMENTAL

• Temperature, Operating (°C): 5°C – 55°C
• Shock, Operating, 2ms (Gs): 25
• Shock, Nonoperating, 2ms (Gs): 400
• Acoustics, Typical Idle (bels): 2.8
• Acoustics, Typical Seek (bels): 3.2
