ST1000DX002

SPECIFICATIONS

• Capacity: 1TB
• Interface: SATA 6Gb/s NCQ
• Form Factor (in): 3.5
• Recording Technology: CMR
• Bytes per Sector: 4096

FEATURES AND PERFORMANCE

• NAND Type/Size: MLC/8GB
• SATA Transfer Rates Supported (Gb/s): 6.0/3.0/1.5
• Seek Average, Read (ms): <8.5
• Seek Average, Write (ms): <8.5
• Average Data Rate, Read, Avg All Zones (MB/s): 156
• Average Data Rate From NAND Media (MB/s): 190
• Max Sustained Data Rate, OD Read (MB/s): 210Mb/s
• DRAM Cache (MB): 64

RELIABILITY

• Load/Unload Cycles: 300000
• Nonrecoverable Read Errors per Bits Read, Max: 1 per 10E14
• Predicted Annualized Failure Rate (AFR): <1%
• Warranty, Limited (years): 5

POWER MANAGEMENT

• Operating Power, Typical (W): 5.9
• Idle2 Power, Typical (W): 3.36
• Standby Mode/Sleep Mode, Typical (W): 0.63/0.63

PHYSICAL

• Height (mm/in, max): 19.87mm/0.782in
• Width (mm/in, max): —
• Depth (mm/in, max): 146.99mm/5.787in
• Weight (g/lb, typical): 400g/0.88lb
• Carton Unit Quantity: 25
• Cartons per Pallet/Cartons per Layer: 40/8

ENVIRONMENTAL

• Temperature, Operating (°C): 0 to 60
• Temperature, Nonoperating (°C): −40 to 70

CONFIGURATION

• Heads/Disks: 2/1
